Product Details:
|
| Model Name: | Fiber Optics Connector | Connector Type: | SC/FC/LC/ST/MTRJ/MU/MPO Ect |
|---|---|---|---|
| Ferrule End-face: | PC,UPC,APC | Fiber Type: | Singlemode, Multimode |
| Color: | Blue,Green,Grey,Aqua,Purple Etc | Cable Applicable: | 3.1 X 2.0 Mm Drop Cable |
| Installation Time: | Within 60s ( No Fiber Cut ) | Sleeve: | Caremic/Phosphor Bronze |
| Highlight: | 900um LC APC fiber connector,2.0mm LC APC fiber connector,900um simplex fiber optic connector |
||
LC/APC Simplex Single Mode 900um Green Boot Fiber Optics Connector
Brief Introduction:
Geehe's single-mode LC/APC connectors are specially designed to provide low insertion loss and back reflection, along with high precision and mechanical stability.
Our male LC connectors are designed to terminate two fibers into a single polymer ferrule.
These connectors comply with Telcordia -326-Core interpretability standards and conform to RoHS environmental requirements
Fiber Optic connectors Features and Advantages:
Ferrule end surface pre-domed
Boots in a variety of colors
Telcordia style boots
Clips are available for SC and LC duplex connectors
Good exchangeability and good durability
Application of LC Connector:
Technology Specification& Parameters:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3；MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| Interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥50 | ≥50 |
| MM | dB | ≥36(Exclusive APC Connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
Order Information:
| OFC | -X | -XX | -XX | -XX | -X | -X |
| S: Simplex D: Duplex |
LA:LC/APC LC:LC/UPC LP:LC/PC | LA:LC/APC LC:LC/UPC LP:LC/PC | 09:0.9mm 20:2.0mm 30:3.0mm | 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others | 0.5:0.5m 1.0:1.5m 10:10.0m |
|
| Fiber Mode | Connector Type | Connector Type | Cable Diameter | Fiber Type | Fiber Length |
More fibre optic connector types:
Wuhan Geehe Comm Service:
1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity
2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space
3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards
4) Fast Delivery
All the order turn over is very fast and every step will feedback to customers
