1x4 Mini Module 900μm SC/UPC LZSH Singlemode Fiber Optic Y Splitter

Large Image : 1x4 Mini Module 900μm SC/UPC LZSH Singlemode Fiber Optic Y Splitter

Product Details:

Place of Origin:	China Mainland
Brand Name:	Geehe Comm
Certification:	ISO9001:2015, RoHs,CE
Model Number:	GH-PLC-1X4 -0012

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	Negotiation
Packaging Details:	Plastic box per pc with Pressure defense sponge, outer carton
Delivery Time:	7-9 working days after confirm PI TODAY
Payment Terms:	Sinosure, L/C, T/T, D/A, D/P, MoneyGram
Supply Ability:	6,800 Pcs/day

Contact Now

1x4 Mini Module 900μm SC/UPC LZSH Singlemode Fiber Optic Y Splitter

Description

Model Name:	Fiber Optic Y Splitter	Cable Type:	9/125um Single-mode
PLC Casing Type:	Micro PLC	Splitting Ratio:	1x4
Cable Diameter:	900um	Fiber Length:	Customized Length1M, 1.5M, 2M, 2.5M, Custom
Fiber Type:	G657 Grade A Optical	Port Wavelength:	1310-1550nm
Package:	Steel Tube, ABS Black Box, Rack, Module	Length:	1m Or 1.5m
Highlight:	900μm SC/UPC Fiber Optic Y Splitter , LZSH Singlemode Fiber Optic Y Splitter , 900μm 1x4 Fiber Optic Y Splitter

1x4 Mini Module 900μm SC/UPC LZSH Singlemode Fiber Optic Y Splitter

Quick Overview:

PLC-1 × 4 -E-SM-SC/UPC
Fiber Optic Splitter, Tube Type, PLC
Connector Type: SC/UPC
Split Type: 1×4, Stainless steel package
Single Mode
Fiber: 0.9mm Cable 1.5 m long
Package: Wooden box with the designed inside box
Easy Installation
GR-1209/1220-Core Standard

Our Single Mode, Multimode, and Planar Waveguide Splitters are designed and manufactured to provide low loss and excellent uniformity over wide temperature ranges. Available in a variety of configurations.

Commonly used for connections in optical distribution box or network cabinet for Fiber to the point (FTTx) deployments, CATV links and other passive optical networks (e.g., GPON).

1x4 Mini Module 900μm SC/UPC LZSH Singlemode Fiber Optic Y Splitter 0

PLC Splitter Features&Benefit:

Singlemode PLC Splitters in a variety of package types and configurations
Optical performance 100% factory tested
UPC, and APC polish types available for connectorized products
Low Insertion Loss, Back Reflection and PDL
Wide Wavelength Range, High Uniformity
Environmentally Stable
Telcordia GR-CORE 1221 certified

Application&Standard:

LAN, WAN & Metro Networks
Telecommunication Networks
Passive Optical Networks
FTT(X) Systems
CATV
Value Added Module

1x4 Mini Module 900μm SC/UPC LZSH Singlemode Fiber Optic Y Splitter 1

Specification& parameters:

Parameter	1x4	1x8	1x16	1x32	1x64	2x4	2x8	2x16	2x32
Operating Wavelength(nm)	1260~1650
Port Wavelength Range (nm)	1310 ±20,1490 ±10 and 1550 ±20
Insertion Loss @1310nm/1550nm	7.1	10.5	13.6	16.8	20.5	7.4	10.8	14.5	17.5
Uniformity (dB)	0.5	0.8	1	1.2	1.8	1.2	1.5	1.8	2
PDL @ 1310/1550 nm (dB)	≤0.3
Return Loss@ 1310/1551 nm (dB)	≤-55
Input Power (mW)	250max
Operating Temperature (℃)	-40~+85℃
Storage Temperature (℃)	-40~+85℃
Fiber Type	Corning G657A1

PLC Splitter Package Dimensions:

WxHxD(mm)	Port
60x7x4	1x4	1x8	2x4	2x8
60x12x4	1x16		2x16
80x12x6	1x32		2x32
100x40x6	1x64

Ordering Information:

PLC	AAA	B	CC	D	EE	FF	GG
	104=1x4 108=1x8 …… 164=1x64 204=2x4 …… 232=2x32	1=900µm loose	05=0.5m 10=1.0m 15=1.5m 20=2.5m	1=900µm loose	05=0.5m 10=1.0m 15=1.5m 20=2.5m	SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector	SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector
	Configuration	Input Fiber Type	Input Fiber Length	Output Fiber Length	Output Fiber	Input Connector	Output Connector

Geehe Comm Service:

Provide the highest quality of products
Continuous improvement; accepting new challenges
Innovating new processes, and creating new products for the benefit of our customers
Consultative service and strive to ensure a positive and productive experience
Efficient use of all transportation modes and transit times
Greater visibility and real-time information
Younger team with more energy to supply VIP service for every customer
24/7 service line:+86 13429864799
Fast turnover and delivery for orders with familiar and mature workers

1x4 Mini Module 900μm SC/UPC LZSH Singlemode Fiber Optic Y Splitter 2
