Product Details:
|
| Model Name: | SC To ST Fiber Optic Hybrid Adapters | Fiber Counts: | Simplex |
|---|---|---|---|
| Adapter Insert Material: | Zirconia/Ceramic, Metal | Housing Material: | Metal, Plastic |
| Connector Type: | SC/APC,LC/UPC,FC/APC Etc | Fiber Mode: | Single Mode |
| Durability: | >1000 Mating Times | Operating Temperature: | -40~75℃ |
| Adapter Mounting Type: | Flange | ||
| Highlight: | SC To ST Fiber Optic Hybrid Adapters,Single Mode Fiber Optic Hybrid Adapters,SC TO ST Hybrid Adapter |
||
High-Precision Sleeve Single Mode SC To ST Fiber Optic Hybrid Adapters
1. Product Overview:
SC/ST Hybrid Adapter offers a solution for any hybrid applications where SC interconnect systems are incorporated into ST system configurations or vice versa.
The adapter’s high-precision sleeve enables reliable ferrule mating of the SC and ST ferrule diameters, ensuring low insertion and return loss.
The SC/ ST adapter is available with square or rectangular flange, and metal or polymer housing.
Geehe hybrid adapters comply with international standards and are subject to the strictest quality control throughout the manufacturing process.
2. Optical Cable Adaptor Feature and Benefits:
3. Fiber Optic Adapter Applications:
4. Optic Adapter Specification & Technology Parameters:
| parameter | SC, FC, ST, LC, MU, ST |
| End-face | APC/UPC/PC |
| Mode | Single-mode & multi-mode |
| Sleeve | Zirconia ceramic, phosphor bronze |
| Insertion loss (dB) | ≤0.2 |
| Exchangeability (dB) | ≤0.2 (connect randomly) |
| Tensile strength (dB) | ≤0.2 (0~100N) |
| Vibration (dB) | ≤0.2(5~50Hz, 1.5mm amplitude) |
| Temp. Range (dB) | ≤0.2(-40~80℃, 21 cycles) |
5. Ordering Information:
EX: OFA-D-FC-APC-Z-N-N
| OFA | -X | -XX | -XX | -XX | -X | -X |
|
S: simplex D: duplex |
SC FC ST LC MU ST |
APC UPC PC |
Z: Zirconia ceramic, P: phosphor bronze |
W: with flange N: no flange |
W: with shutter N: no shutter |
|
| Fiber mode | Connector Type | Connector Type | Sleeve | Flange type | Shutter type |
| Parameter | Unit | Value |
| Connector | / | FC ST SC-LC |
| Sleeve | / | Zirconia |
| Insertion Loss | dB | ≤0.20(Plug≤0.30) |
| Repeatability | Time | ＞1000 |
6.More Options Optic Adapters:
7. Wuhan Geehe Comm Service:
1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity
2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space
3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards
4) Big Production Capacity
800 Skilled workers and 5 Main production Lines, the optic adapter 8,900 pcs/ Day. Free samples can be support for testing.
