Product Details:
|
| Model Name: | Single Mode Patch Cord SC-SC | Cable Diameter: | 3.0mm |
|---|---|---|---|
| Cable Material: | PVC,OFNR | Polishing: | UPC,APC,PC |
| Cable Grade: | FDDI Riser Rated OFNR | Cable Length: | 1M,2M,3M...customize |
| Cable Dimensions: | 3.0mm | Cable Sheath Color: | Yellow,Orange, Lime Green Etc |
| Fiber Type: | SM,MM | ||
| Highlight: | 9/125 Single Mode Fiber Patch Cable,SC SC Single Mode Fiber Patch Cable,2M sc sc fiber patch cord |
||
2M Corning SC/SC Simplex 9/125 Single Mode Fiber Patch Cable
1. Fiber Patch Cord Basic Introduction:
Fibre Patch cords or pigtails are the non-permanent connection between patch panels, transmission equipment, or customer premise. Pre-assembled patch cords meet Telcordia or Grade B Random mating specifications, dependent on your network infrastructure requirements, and provide a complete "plug & play" solution.
Pre-assembled patch cords make it is possible to install or deploy large cabling systems rapidly with single fibre or multi-fibre patchcord solutions. Cable jacket options from OFNR, LSZH, or the new ratings.
2.Fiber Optic Patch Cord SC To SC
3. Single Mode SC To SC Patch Cord Application:
4.Specification&Technology Parameters
| Parameters | Value | ||||
| Connector Type | LC/UPC,LC/UPC | ||||
| Center Wavelength(nm) | 1310 or 1550 | ||||
| Max.Insertion Loss(dB) | 0.3 | ||||
| Min.Extinction Ratio(dB) | 23 | ||||
| Min.Return Loss(UPC) (dB) | 50 | ||||
| Min.Return Loss(APC) (dB) | 60 | ||||
| Key Orientation | Slow Axis | ||||
| Axis Alignment(deg) | ±3 | ||||
| Operating Temperature(℃) | -20~+70 | ||||
| Storage Temperature(℃) | -40~+85 | ||||
| FIber Type | PM Panda Fiber | ||||
* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER is 2dB lower.
* The default connector key is aligned to the slow axis.
5. Fiber patch cord SC Specification& Technology Parameter:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3; MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥50 | ≥50 |
| MM | dB | ≥36(Without APC connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
* EX:OFC-D-LA-LA-09-1-1.0
